1
Cilindrada
500
2
Año
1996
3
Acabado
SPORTSMAN 500 - W969244
4
Catálogo de recambios
CABINA SPORTSMAN 500 W969244 AND SWEDISH SPORTSMAN 500 S969244 (4936093609A005)
5
Despiece
Catálogo de recambios
MAGNETO SPORTSMAN 500 W969244 AND SWEDISH SPORTSMAN 500 S969244 (4936093609D013)
por
MONTAJE DEL MOTOR SPORTSMAN 500 W969244 and SWEDISH SPORTSMAN 500 S969244 (4936093609A011)
CABINA SPORTSMAN 500 W969244 AND SWEDISH SPORTSMAN 500 S969244 (4936093609A005)
1
2
2
2
2
3
3
4
5
6
7
7
8
9
10
11
12
12
12
12
13
14
15
16
17
18
18
18
18
19
20
21
22
1
2
2
2
2
3
3
4
5
6
7
7
8
9
10
11
12
12
12
12
13
14
15
16
17
18
18
18
18
19
20
21
22
1
FOIL FOAM SIDEPANEL
5810996
No disponible
2
PANEL/FOIL ASM RH OLV.GRN. (Incl. Foil & Foam)
2620085191
No disponible
2
PANEL LH SIDE OLV.GREEN
5431809191
No disponible
3
SCREW(10)
7522026
No disponible
4
COVER FRONT BLK
5432088070
No disponible
5
Clip Spring
7670085
6,38€ Precio unitario con IVA
6
CAB ASM FR OLV.GRN. Substituted by 2631927-191 (Incl. Warning Decals)
2631734191
347,30€ Precio unitario con IVA
7
NUT U-TYPE SPEED
7670057
2,39€ Precio unitario con IVA
8
DESC NOT_AVAILABLE
7522017
No disponible
9
Rivet
7661645
No disponible
10
PALNUT(10)
7670009
No disponible
11
CLAMP HOSE
7080660
No disponible
12
SHIELD RH DEFLECTOR
5811098
No disponible
12
SHIELD LH DEFLECTOR
5811096
No disponible
13
CLIP-PLASTIC DART NYLON
7670088
3,18€ Precio unitario con IVA
14
NUT NYLOK
7542122
2,39€ Precio unitario con IVA
15
SCREW(10)
7512017
No disponible
16
WASHER(10) Substituted by 7558221
7555931
7558221
4,79€ Precio unitario con IVA
17
FUEL LINE-1/4 ID (SVC) 600 CM [BULK]
8450040600
127,91€ Precio unitario con IVA
18
MUDGUARD RH FRT.BLK. Substituted by 5431799-070
5431799
66,83€ Precio unitario con IVA
18
MUDGUARD LH FRT.BLK. Substituted by 5431798-070
5431798
66,83€ Precio unitario con IVA
19
SCR-TFHFL-1/4-20X0.75 CHS ZY3
7512232
2,39€ Precio unitario con IVA
20
NUT LOCK(10) Substituted by 7541925
7541929
7541925
1,81€ Precio unitario con IVA
21
WASHER-.20X.67X.048-Y
7555792
8,23€ Precio unitario con IVA
22
Screw
7512085
2,22€ Precio unitario con IVA

En esta página encontrará el esquema detallado CABINA SPORTSMAN 500 W969244 AND SWEDISH SPORTSMAN 500 S969244 (4936093609A005) POLARIS. Esta vista explosionada permite identificar los diferentes componentes que necesita para mantener su máquina y encontrar rápidamente su referencia de pieza original POLARIS.


Los esquemas no son contractuales. En caso de duda, nuestros profesionales están disponibles para responder a sus preguntas. Al añadir una pieza al carrito, asegúrese de solicitar la cantidad deseada. El precio unitario indicado corresponde al precio de cada referencia para una cantidad de 1.
