1
Cilindrada
500
2
Año
1996
3
Acabado
SWEDISH SPORTSMAN 500 - S969244
4
Catálogo de recambios
puntal delantero SPORTSMAN 500 W969244 (4936093609B005)
5
Despiece
Catálogo de recambios
DEL EJE DE PROPULSIÓN SPORTSMAN 500 W969244 AND SWEDISH SPORTSMAN 500 S969244 (4936093609B004)
por
MANILLAR y la linterna POD SPORTSMAN 500 W969244 and SWEDISH SPORTSMAN 500 (4936093609B010)
puntal delantero SPORTSMAN 500 W969244 (4936093609B005)
1
BUMPER STRUT Substituted by 5411468
5410791
18,73€ Precio unitario con IVA
2
STRUT FRONT 32MM. Substituted by 7041755
7041374
2201460
283,04€ Precio unitario con IVA
3
WASHER-2.06X2.62X.105-Y [BJ/BK/BX/B9]
5211115
7,98€ Precio unitario con IVA
4
CLAMP RUBBER-COATED .562(10)
7080573
12,36€ Precio unitario con IVA
5
WASHER-.344X.688X.063 FL-Y
7558402
1,81€ Precio unitario con IVA
6
NUT FLEX-LOC(10)
7542303
No disponible
7
SCREW CAP(10) [CALIPER MOUNTING]
7512365
2,39€ Precio unitario con IVA
8
WASHER-5/16 SPRING LK-MED-Y
7552901
2,39€ Precio unitario con IVA
9
RETAINER WIRE STRUT CAST
5810439
No disponible
10
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
No disponible
11
BEARING TAPERED ROLLER
3554509
35,78€ Precio unitario con IVA
12
BRG TAPER ROLL CUP
3554507
47,71€ Precio unitario con IVA
13
SLEEVE STRUT HUB SEAL
5222193
111,91€ Precio unitario con IVA
14
COIL MAGNETIC HEAVY Substituted by 2201313
4170007
2201313
201,67€ Precio unitario con IVA
15
HUBSTRUT ASM LH HVY Substituted by 2201311 (Incl. 9 12-14 16 23)
2200766
263,15€ Precio unitario con IVA
15
HUBSTRUT ASM RH HVY Substituted by 2201312 (Incl. 9 12-14 16 23)
2200767
263,15€ Precio unitario con IVA
16
FITTING LUB W/BALL
7080306
6,38€ Precio unitario con IVA
17
Spring Compression
7041375067
7042312-067
119,90€ Precio unitario con IVA
18
RETAINER SPRING TOP (Before 11/2/98)
5220602
No disponible
19
PIVOT BALL BOTTOM Substituted by 5432871
5430807
5432871
14,30€ Precio unitario con IVA
20
SPACER THREADED (Before 11/2/98)
5130668
41,75€ Precio unitario con IVA
21
SCR-HH-5/16-18X2.25 GR5 ZY3
7515339
8,23€ Precio unitario con IVA
22
SHOCK FTA [SEE PAGE- SUSPENSION SHOCK FRONT TRACK]
*******
No disponible
23
SEAL HUB STRUT
3610028
47,71€ Precio unitario con IVA
24
PIVOT BALL TOP Substituted by 5432872
5430806
5432872
13,12€ Precio unitario con IVA
25
SPACER-RUBBER
5810291
7,98€ Precio unitario con IVA
26
WSHR-.500X1.50-12GA-Y
7555749
2,39€ Precio unitario con IVA
27
NUT FLEX LOC(10)
7542507
No disponible

En esta página encontrará el esquema detallado puntal delantero SPORTSMAN 500 W969244 (4936093609B005) POLARIS. Esta vista explosionada permite identificar los diferentes componentes que necesita para mantener su máquina y encontrar rápidamente su referencia de pieza original POLARIS.


Los esquemas no son contractuales. En caso de duda, nuestros profesionales están disponibles para responder a sus preguntas. Al añadir una pieza al carrito, asegúrese de solicitar la cantidad deseada. El precio unitario indicado corresponde al precio de cada referencia para una cantidad de 1.
